Windproof 20 × 30 Aluminum Frame Tent With Pvc Or Glass Wall

Windproof 20 × 30 Aluminum Frame Tent With Pvc Or Glass Wall

20 × 30 aluminum frame tent

3m Aluminum Frame Tent

100km/h Aluminum Frame Tent

Place of Origin:

Hebei, China

Brand Name:




Model Number:

Event tent

Contact Us
Request A Quote
Product Details
Main Material:
Aluminum Alloy
PVC Walls,glass Wall,ABS Wall,etc.
Fabric Color:
White,black,red Or As Requested
Width Of Tent:
Eave Height:
Standard 2.5m, 3m, 4m, 5m Upon Span Width
Max Wind Allowed:
100km/h ( 0.3-0.5kn/sqm )
Waterproof, Fire-retardant,Sunshade,Easy Fixed
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
1.aluminum frame packed in box; 2.hardware packed in solid carton box; 3.roof and sidewall in professional PVC carry bag; 4.customized package
Delivery Time
About 15 days
Payment Terms
T/T, Western Union
Supply Ability
10000 Sets Per Month
Product Description


Windproof 20 × 30 Frame Tent With PVC or Glass Wall

1. Application of Outside Aluminum Frame Tent:
Widely used for party, outdoor exhibition, outdoor wedding, church, trade fair, celebration, restaurant,sports event, temporary warehouse, storage and workshop.
2. Technical Parameter of Outdoor Tent For event, wedding, warehouse:

A-Frame Tent Type for Warehouse, workshop
Model Width Length Bay distance Side height Ridge height Max. wind load
JN006 6m Unlimited 3m 2.70m 3.90m 80km/h
JN008 8m Unlimited 3m 2.70m 4.30m 80km/h
JN010 10m Unlimited 3m 2.70m 4.70m 80km/h
JN12 12m Unlimited 5m 3.00m 4.90m 100km/h
JN015 15m Unlimited 5m 4.00m 6.40m 100km/h
JN018 18m Unlimited 5m 4.00m 6.90m 100km/h
JN020 20m Unlimited 5m 4.00m 7.20m 100km/h
JN025 25m Unlimited 5m 4.00m 8.00m 100km/h
JN030 30m Unlimited 5m 4.00m 8.90m 100km/h
JN040 40m Unlimited 5m 4.00m 10.50m 100km/h
JN050 50m Unlimited 5m 4.00m 12.00m 100km/h


3. Characteristics

1) High quality aluminum alloy frame, strong and durable.
2) Temperature resistance:-30~70C;Flame retardant to DIN4101B1(grade:B1);
    Windproof(allow wind speed 80~100km/h);UV resistant.
3) Easy assembled and dismantled, the best choice for outdoor activities.
4) No bearing column in the structure, you can use the most of space . No special requirements for sites,       which can be easy to assemble on grass, sand, concrete and so on.
4. Frame Material & Cover Material
1) Hard pressed extruded aluminum GB6061/T6(13HW).
2) Connector is made of zinc powder-coated steel.
3) The frame is strong,durable,light in weight,not easy to rust and distort.
4) Double PVC-coated polyester textile.Any color is available.
5) Waterproof, flame retardant to DIN4102 B1, M2, UV resistant.
6) 750g/sqm, 850g/sqm PVC for roof cover, 650g/sqm PVC for sidewall.
7) The maximum allowed wind speed is 102km/h.
1). Guaranteeing quality but reducing cost by many years' experience.
2). Focusing on global PVC tents market and requirements.
3). Innovating hardware design for more trendy and convenient.
4). In order to improve efficiency, suppliers of raw material are neighboring.
5). 100% inspection before exporting and 100% after-sales service following.
6). On going creation and innovation can go beyond.

6. Event Tent Accessories:

1.Lining,curtain: Fit for large activities, decorating inside ,different colors as customers' request
2.PVC Clear Windows: Transparent,wind-proof and rain-proof (FREE)
3.Expansion Screw: install the tent on the cement or tarmac ground(FREE)
4. steel nails: install the tent on the grass or sand ground
5.Weight plate : The best safe install way ,install tent on the marble or tile ground
6.Flooring system: Perfect decoration for any activities (wooden floor)
7.Glass wall/doors system: Single door or double wing door for you choose
8.Air conditioning system : 3p or 5p or 10P
9.Rain gutter:we offer our best project based on your needs
10.Carpet:different colors are available
11.Decorative lightings:LED light or chandelier
12.Table: 1.5m and 1.8m round table(8-10people) or rectangle table
13.Chairs:steel chairs,folding chairs and luxury Chiavari Chair with cover
14.Sidewall Option:White PVC wall,Transparent PVC wall,Glass wall,ABS wall,Sandwich wall
