PVC Fabric Cover Aluminium Pagoda Tent Retardant 100 Km / H Wind Loading

PVC Fabric Cover Aluminium Pagoda Tent Retardant 100 Km / H Wind Loading

aluminum frame canopy tents

outside party tents

Place of Origin:

Hebei, China

Brand Name:




Model Number:

Outdoor tent

Contact Us
Request A Quote
Product Details
Main Material:
Aluminum Alloy
PVC Walls,glass Wall,ABS Wall,etc.
Fabric Color:
White,black,red Or As Requested
Width Of Tent:
Eave Height:
Standard 2.5m, 3m, 4m, 5m Upon Span Width
Max Wind Allowed:
100km/h ( 0.3-0.5kn/sqm )
Waterproof, Fire-retardant And Sunlight Proof
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
1.aluminum frame packed in box; 2.hardware packed in solid carton box; 3.roof and sidewall in professional PVC carry bag; 4.customized package
Delivery Time
About 15 days
Payment Terms
T/T, Western Union
Supply Ability
10000 Sets Per Month
Product Description

PVC Fabric Cover Aluminium Pagoda Tent Retardant 100 Km / H Wind Loading


1. Description of Aluminium Pagoda Tent:


Main Profile Hard pressed extruded aluminium 6061/T6 or 6082-T6
Cover doulbe pvc coated polyester. It is high quality at waterproof, flame retardant to DIN4102 B1,M2,U V resistant, self-cleaning ability. Roof cover is 850g/sqm pvc, sidwall cover is 650g/sqm pvc
Eave Connection Hot-dip Galvanized steel insert,tough and anti-rust
Wind Loading 100km/h
Temperature Resistance -30 degree Celsius to +70 degree Celsius
Fixing Solution expansive bolts, loading plate, ground anchor
Pagoda Accessories Ground anchor, anchor puller, weight plate, clear pvc wall, glass wall, glass door, ABS hard wall, decoration roof lining and sidewall curtain, floor, air conditioner etc., chairs , tables, & other furniture for the parties are also optional
Pagoda Application It is wdely used for outdoor promtiom, exhibition, advertising, wedding, party, celebration, sports event, temporary reception house and so on.


2. Product technical parameter of Aluminum Pagonda Tent:


  specifications Width Length Eave height Ridge height
63x62x2.5mm 3x3m 3m 3m 2.6m 4.1m
63x62x2.5mm 4x4m 4m 4m 2.6m 4.6m
63x62x2.5mm 5x5m 5m 5m 2.6m 5.1m
63x62x2.5mm 6x6m 6m 6m 2.6m 5.6m
84x48x2.5mm 8x8m 8m 8m 2.6m 5.3m
84x48x2.5mm 10x10m 10m 10m 2.6m 5.7m


3. Cover Material of Wedding Marquee Tent:


Fabric material double pvc coated polyester textile
Density of PVC 850g/sqm for roof
650g/sqm for side walls
Characteristics Waterproof, flame retardant to DIN4102 B1, M2, U V resistant, UV resistant
PVC color White or any color is available
Life span 5-8 Years


4. FAQ:


Q: How can I inquire?
Provide the size you need (width x length), or for how many people you need the tent to contain, we will recommend the size to you according to your demand.

Q: What is the material of your tents?
Our tent frame is reinforce Aluminum; fabric material is 850g/m² for roof and 660g/m² for
walls, Double PVC-Coated Polyester. Our tent structure is safe, strong and can resist wind up to 100km/h.

Q: Can you print our logos on tent?
Yes, we can print your logo on the tent fabric according to your requirement.

Q: Is the tent easy to install and take down?
We will send you installation manual as well as the installation video, and you can come to our factory to learn how to install the tent.

Q: Is the tent able to install repeatedly?
Yes. The tent can last more than 20 years, and it is suitable for rental business. It can be assembled and dismantled repeatedly.


PVC Fabric Cover Aluminium Pagoda Tent Retardant 100 Km / H Wind Loading 0

PVC Fabric Cover Aluminium Pagoda Tent Retardant 100 Km / H Wind Loading 1
