Place of Origin:
Hebei, China
Brand Name:
JN
Certification:
CE ISO
Model Number:
Customize
Soil Belt Conveyor With Large Conveying Capacity For Loading And Unloading
Description & Application
The Soil belt conveyor with large conveying capacity for loading and unloading is a kind of continuous mechanical handing equipment with high efficiency, good safety and good mobility. Mainly used for short-distance transport, handing of bulk material and the product one-piece weight less 100kg on loading and unloading stations which are often changed, such as the port, terminal, station, coal yard, warehouse, building site, sand quarry, farm and so on. It can be divided into lift and not lift type, the running of belt is driven by electric-roller, and the whole lifting and running are non-motorized.
Specification / Technical Parameter:
| Width(mm) | Length(m)/Power(kw) | Speed(m/s) | Capacity(t/h) | ||
| 400 | ≤12/2.2 | 12~20 /2.2~4 | 20~25/3.5~7.5 | 1.25~2.0 | 30~60 |
| 500 | ≤12/3 | 12~20/3~5.5 | 20~30/5.5~7.5 | 1.25~2.0 | 40~80 |
| 650 | ≤12/4 | 12~20/4~5.5 | 20~30/5.5~11 | 1.25~2.0 | 80~120 |
| 800 | ≤10/4 | 10~15/4~5.5 | 15~30/5.5~15 | 1.25~2.0 | 120~200 |
| 1000 | ≤10/5.5 | 10~20/5.5~11 | 20~40/11~22 | 1.25~2.0 | 200~320 |
| 1200 | ≤10/7.5 | 10~20/7.5~15 | 20~40/15~30 | 1.25~2.0 | 290~480 |
Advantages:
The Soil belt conveyor with large conveying capacity for loading and unloading can be widely applied to the bulk material and packaged bag items in industries like coal, metallurgy, chemical engineering, hydroelectricity, traffic, building material and so on. Its performance and main technical parameters are equal to Germany Flender and Thyssen company's products.It can be used for not only horizontal conveying, but also inclining conveying in which there is inclination and uneven segment. With simple structure, high precision and long lifetime, it is used conveniently and universally.
Note:The conveying amount in the table is formulated on the condition that the material’s specific weight r=1 t/m3 , the conveyer’s inclining angle is 0~7°, and the angle of repose is 30°
Redesign for customer’s special demand is available.
If you want to order our products, please answer to these questions carefully. So that we can better to help you to chose the matching model
1. What's the material will you transported, bag material or bulk material
2. If bag material, please tell us the weight of every bag, If bulk material, please tell us the capacity?
3. What's the length and the lifting height do you required?
