VFD Motors 3*11KW Twin Cage 2000KG Building Hoist

VFD Motors 3*11KW Twin Cage 2000KG Building Hoist

2000KG Building Hoist

3*11KW Building Hoist


Place of Origin:

Hebei, China

Brand Name:




Model Number:


Contact Us
Request A Quote
Product Details
Rated Loading Capacity:
Hoisting Speed:
Max Lifting Height:
Free Standing Height:
Motor Power:
Mast Section Size:
Passenger No.:
Payment & Shipping Terms
Minimum Order Quantity
1 Sets
Packaging Details
Standard export package with 20ft, 40ft and 40HQ container.
Delivery Time
Within 20 days
Payment Terms
T/T, Western Union, L/C
Supply Ability
60 sets per month
Product Description


VFD Motors 2*3*11KW Twin Cage 2000KG Construction Hoist Elevator


Features and advantages Of construction hoist elevator


SC200 Construction Hoist Elevator adopted computer aided design. Comparing with traditional construction hoists, it is attractive, light, easy to handle, secure, applicable, and popular.
Depending on special needs of regular or irregular sections, the lifting capacity can reach up to 1~2 tons, and the running speed can reach 28~38m/min. Moreover, VFD speed regulation and PLC enable 0~68 limitless speed, automatic layer selecting and leveling as required.


SC200 Construction Hoist is excellent in technical performance, more secure in operating mechanism, and more compact in structure.


* The modular and standardizing system makes the Kangbo construction hoist elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.
* The material hoist runs without vibration or trembling. The man and material lift starts and stops without surging or jerking.
* The Construction Hoist Elevator is reliable with very little breakdown and is durable with very long work-life.
* Adopt energy-saving helical reducers made specially for rack and pinion elevators, extremely strong, reliable and durable.
* Racks centering at mast reduce partial load torque of builders hoists, makes the construction hoists run more stably and smoothly.
* Applying non-eccentric rollers, make the installation of construction site elevators be faster and easier, with much less error.
* The integrated elevator car roof, which made by a steel plate with edges fully welded one time to complete, enhance hoist cage strength and ensure no water leakage.
* Easy access to electrical panels of elevator for maintenance
* Certified safety braking system of rack and pinion hoist.


Main Performance Parameter


Item Unit SC100 SC100/100 SC200 SC200/200
Rated loading capacity Kg 1000 2×1000 2000 2×2000
Passenger number Person 12 2×12 16 2×16
Rating rising rate M/min 36 36 36 36
Max. lifting height M 200 200 200 200
Motor power KW 2×11 2×2×11 3×11 2×3×11
Cage size M 3*1.3*2.3 3*1.3*2.3 3*1.5*2.3 3*1.5*2.3
Mast section dimension M













Steeve rating rising weight Kg 200 200 200 200
Main material Steel Q345B
Surface treatment Painted or Hot galvanized
Color Red/yellow/blue/orange etc. It can be OEM.









VFD Motors 3*11KW Twin Cage 2000KG Building Hoist 0

VFD Motors 3*11KW Twin Cage 2000KG Building Hoist 1
