Place of Origin:
Hebei, China
Brand Name:
JN
Certification:
CE ISO SGS
Model Number:
Customized Aluminium Alloy Window
Security Aluminum Window And Door With Double Tempered Glass 4mm
Product Application:
Application of thermal break aluminium window covers curtain wall, windows & doors, railing, decoration, electronics, transportation, etc. especially equipment frame.
Various windows are widely used in house, commercial buildings, hotels, curtain wall, etc, including:
Aluminum sliding window, side-hung window, Sliding windows, aluminium window, aluminum windows, metal window, aluminum alloy window, glass window, window glass, window profiles, heat insulation window, hung window, double hung window, casement window, exposed framing glass curtain wall profiles, hidden framing glass curtain wall profiles, glass curtain wall profiles, thermal break glass curtain wall profiles, curtain wall facade, glass curtain wall.
Technical Parameter:
| Item | Security Aluminum Window And Door With Double Tempered Glass 4mm |
| Profile | 1. 6063-T5/T6 normal aluminum,thermal break aluminum 2. pvc/upvc/VINYL(China top brand CONCH/German Brand REHAU/Korea brand LG) |
| Glass |
1.Double tempered glazing:5mm+12A(Air)+5mm; 5mm+12A+5mm tinted; 5mm+12A+5mm Low-E; 5mm+27A+5mm 2.Single tempered glazing: 3/4/5/6/8/10/12/15/19/21mm 3.Laminated glazing: 5mm+0.76+5mm, 5mm+0.38+5mm |
| Hardware |
1. German brand: Roto, Siegenia, Geze 2. Chinese brand: Kinlong,Hopo |
| Mesh |
1. Stainless steel security mesh 2. Aluminium security mesh 3. Fiberglass flyscreen 4. Retractable flyscreen |
| Surface treatment |
1. Powder coating 2. Anodized 3. Electrophoresis 4. Wood grain 5. Fluorine carbon coating |
| Parameters |
Double glass sliding windows Sounds insulation: RW ≥ 30 dB Wind pressure resistance: 4500 pa Air permeation resistance: 70/150 Water resistance: 450mm N6 CLASS based on AS2047 STANDARD |
| Warranty | Ten years |
Aluminum alloy window door feature:
1) Frame colors available in White and others
2) Available with multi-panel, multi-track by-pass and pocket
3) Good air-tightness, water-tightness, sound and heat insulation.
4) Good wind-resistance, widely used for windy/storm areas.
5) Durable, no deformation, no crack after long-time usage.
6) Surface treatment: Anode Anodizing, Electrophoresis Coating, Powder Coating, Fluorocarbon Coating, PVDF Painting, Break-Bridge and Heat Insulation, Film Attaching.
7) Hardware system: High quality hardware, domestic top brand and imported German ROTO, SIEGWNIA.
Packing of aluminum alloy window door:
Our standard package will be use EPE+waterproof plastic film, could be save more space when loading. Also can provide bubble bag+carton+wooden case package to protect the goods.
20 container(20GP) can load 26 cubic meter,around 200 square meter product.
40 container(40HQ) can load 54 cubic meter,around 400 square meter product.
And we are able to customize the package according to customers’ requirement.
