Place of Origin:
Hebei China
Brand Name:
JN
Certification:
CE,ISO
Model Number:
Custom-made
House Building Materials Custom Aluminium Windows Casement Type With Mosquito
Feature:
1. Sound insulation---windows and door are dedicatedly designed and selected, their sealing property is several times higher than that of original windows and doors. They can insulate above 30DB noise outside the windows.
2. Wind proof---strong firmness is ensured by super thick profile and refined three dimensional structural shape design and fixing them with screw on the frames of windows and doors.
3. Watertight and Airtight---imported adhesive tape is used and can be resist aging for over 10 years, the air tightness is less than0.5M/M.H, and the water tightness is more than 350PA, therefore, it can prevent gale and rainstorm from against the air windows.
4. Opening and closing the pulley rail features extremely low friction coefficient, it is easy and smooth to open and close without noise.
5. Water proof---the frames of windows and doors adopt three-cavity design and feature strong rigidity, the independent drain cavity can ensure the smooth drainage in any case.
Aluminium Window And Door:
| Product Name | Tempered Safety Glass Aluminum Casement Windows, Powder Coating Finished |
| Window Type | 70 series aluminum casement window |
| Opening style | casement |
| Opening Pattern | Horizontal |
| Frame Material | Aluminum |
| Color | Cutomized |
| Size | Cutomized |
| Functions | Heat & Sound insulation |
| Profile |
A. Aluminum alloy, 6063-T5, can be thermal break B. Wall thickness: 1.2, 1.4, 1.6, 2.0mm, can be customized C. Surface treatment: anodized, electrophoresis, powder coated, color can be customized |
| Glass option |
A. Single glass: 5,6,7,8,10,12,15,19mm Tempered Glass B. Double glazing: 5+ 6/9/12 +5mm Tempered Glass C. Laminated glass: 5+ 0.38/0.76/1.52PVB+5mm Tempered Glass D. Tinted/Reflect Glass/Tempered Glass E: Customized |
| Hardware | A. Made in China B. Made in Germany C. Customized |
| Fly screen | A. Stainless steel security mesh B. Aluminum security mesh C. Fiberglass fly screen D. Retractable & invisible fly screen |
| Mesh |
1. Stainless steel security mesh 2. Security mesh 3. Nylon screen 4. Mosquito screen |
| Finish |
1. Powder coating 2. Anodized 3. Electrophoresis 4. Fluorine carbon painting |
| Types |
Awning window Sliding window Vertical slide window Casement window Tilt and turn window Fixed window Sliding door Hinge door Bifold door Lift and sliding door Pivot door Escape door Sensor door Glass louver Shutter window |
Packing of aluminum alloy window door:
Our standard package will be use EPE+waterproof plastic film, could be save more space when loading. Also can provide bubble bag+carton+wooden case package to protect the goods.
20 container(20GP) can load 26 cubic meter,around 200 square meter product.
40 container(40HQ) can load 54 cubic meter,around 400 square meter product.
And we are able to customize the package according to customers’ requirement.
