Highways Subways Bridges Tunnels Scaffold Stair Tower Hot Dip Galvanized

Highways Subways Bridges Tunnels Scaffold Stair Tower Hot Dip Galvanized

stairwell scaffold tower

lightweight scaffold tower

Place of Origin:

Hebei, China

Brand Name:




Model Number:

Construction Scaffold Stair Tower

Contact Us
Request A Quote
Product Details
Q235 Steel
Cross Section Size:
2.5m *1.2m
Surface Treatment:
Spray Painted, Hot Dip Galvanized
Highways Subways Bridges Tunnels Construction
As Your Requirements
Socket And Spigot Joints Scaffolding Stair Access Towers
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Standard export package or as requested
Delivery Time
within 7 days
Payment Terms
T/T, Western Union, L/C
Supply Ability
5000m per month
Product Description

Highways Subways Bridges Tunnels Construction Scaffold Stair Access Towers



Brief Introduction :


Stair towers are a necessity when safe and quick temporary access is needed on any new construction, rehabilitation, or industrial project. It is safe and convenient, easy and flexible to assemble and disassemble, and has good bearing capacity. It is highly praised by clients for its advantages.


The main components of safety climbing scaffold are vertical bar, cross bar and inclined bar.




The Socket And Spigot Joints Type Scaffolding Stair Access Towers is widely used in construction of houses, Bridges, overpasses, tunnels, culverts, chimneys, water towers, DAMS and large-span scaffolds.


Technical Parameter:


1. Material: Q235

2. Thickness of vertical tube : 3.25mm

3. Thickness of horizontal tube: 2.2mm

4. Thickness of oblique tube: 1.5mm

5. Height each piece: 3000mm

6. Length each piece: 2500mm

7. Width each piece: 1200mm

8. Weight of each piece : 75KG


Features and advantages:


Each interval of 50CM or 75CM or 100CM on the vertical bar is provided with a row of pin stock, which is made of high-strength steel plate stamping and welded on the steel pipe through special clamps. The welding line length is large and the stability is extremely high. The two ends of the cross bar are respectively set with the corresponding buckle and pin base plug. The range of contact between the cross bar plug and the vertical bar steel pipe is large, with two-way locking function. Each pin base node can be equipped with 4 cross bar joints at the same time.

The reasonable pin base joint structure and vertical bar axial force make the overall structure of the scaffold have high strength in 3d space, good overall stability and reliable self-locking function, which can effectively improve the stable strength and safety of the whole scaffold of the scaffold and better meet the needs of construction safety.


Highways Subways Bridges Tunnels Scaffold Stair Tower Hot Dip Galvanized 0

Highways Subways Bridges Tunnels Scaffold Stair Tower Hot Dip Galvanized 1
