Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier
Description:
Highway guardrails have proven highly effective in reducing the frequency and severity of accidents. A recent Transportation Research Board study determined that guardrails are at least 97% effective in reducing injuries & fatalities. Since their inception during the 1960s, W-beam guardrails have protected millions of travelers by containing or deflecting run-off-road vehicles from impact with roadside hazards.
Machine composition
| Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier Main Components | |||
| No. | Name | Unit | Qty |
| 1 | Decoiler | set | 1 |
| 2 | Main Machine for roll forming | set | 1 |
| 3 | Control System(PLC) | set | 1 |
| 4. | Hydraulic oil pump | set | 1 |
| 5. | Product stand | set | 1 |
| Remark: Decoiler have manual decoiler,Electric decoiler and Hydraulic decoiler,can booking as request | |||
Working Flow of Machine
Decoiler--- Feeding---- Roll Forming ---- Cutting ---- output
Technical Parameter of Highway Guardrail Roll Forming Machine:
| Length of the main part | About15500*1650*1500mm |
| Weight of main part | About 9.5 ton |
| Voltage | 380V/50HZ3Phase (as customer`s request) |
| Roller fixer | Middle plate welded |
| Frame | 400H steel welded |
| Middle plate thickness | 30mm |
| Drive mode | Chain Drice//Gear Drive |
| Material of rollers | GCR15, quenched treated HRC58-62℃ |
| Material of shafts | 45# steel |
| Diameter of shafts | Φ90mm(depend on defferent design) |
| Number of rollers: | 16 rollers |
| Main power | 37kw |
| Cutting&Hydraulic | Double guide pillar |
| Hydraulic motor power | 15kw |
| Hydraulic Pressure | 10-12MPa |
| Cutting drive | Decelerating motor + Chain drive gear all by high-frequency |
| Control System | PLC system: Mitstubishi, Panasonic,Detal,Siemens,Schneider |
| Feeding Material width | Better as your drawing or from our designer |
| Feeding Thickness | 3~4mm |
| Effective width | Better as your drawing or from our designer |
| Productivity | 15m/min |
Features and Advantages:
Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier
♥ Repair parts are off the shelf - making them inexpensive and easily accessible
♥ Cepair parts are off the shelf - making them inexpensive and easily accessible
♥ Allows for radius as low as 355 m
♥ Only 19 inches wide making it ideal for narrow median in construction zones
♥ Low deflection, "fully pinned" option available
Packaging Detail of stud and track roll forming machine :
1. One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
