33m/Min 2 Ton 200m Building Construction Lift

China Gu an Jianneng Trading Co., Ltd certification
China Gu an Jianneng Trading Co., Ltd certification
Customer Reviews
Appreciate for your professional and fast service, hope you can help us do more purchases in the future.

—— Edris

We got our delivery and we are happy with the super quality, thanks a lot, cheers.

—— Bajrang Pandey

You always can give me the best plan ,and it lets my customer feel great, I hope we can have another chance to cooperation.

—— Charles Kasigara Kirama

I'm Online Chat Now

33m/Min 2 Ton 200m Building Construction Lift

33m/Min 2 Ton 200m Building Construction Lift
33m/Min 2 Ton 200m Building Construction Lift 33m/Min 2 Ton 200m Building Construction Lift

Large Image :  33m/Min 2 Ton 200m Building Construction Lift

Product Details:

Place of Origin: Hebei, China
Brand Name: JN
Certification: CE, ISO
Model Number: SC Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 Sets
Price: USD1000~USD6000/SET
Packaging Details: Standard export package with 20ft, 40ft and 40HQ container.
Delivery Time: Within 20 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 60 sets per month
Detailed Product Description
Rated Loading Capacity: 1000KGS/2000KGS Hoisting Speed: 0~33m/min
Max Lifting Height: 200m Free Standing Height: 50m
Motor Power: 2*11kw/3*11kw Mast Section Size: 650*650*1508mm
Cage: 3*1.5*2.3 Passenger No.: 12/16
High Light:

200m building construction lift


33m/min building construction lift


50m building construction lift


2 Ton Cpacity Frequency Building Construction Lift Red Yellow Orange Blue


We can offer the construction elevator with single cage, double cage of 1-ton lifting capacity and 2-ton lifting capacity at present. The types are as follows: SC100 (1-ton lifting capacity each cage), SC200 (2-ton lifting capacity each cage), SC100/100 (1-ton lifting capacity each cage), SC200/200 (2-ton lifting capacity each cage).


The construction elevator we offered is with safety device ,And our elevator also with other safety devices such as reliable safety interlock-devices, safety switch, and breakage protection switch, upper and lower limits and limit switches, etc. Progressive dropping protection device and safety protection hook are provided. The safety design and configuration fully comply with national standards.


A. Main Technical Parameters of Construction Elevator


Model: SC100 SC100/100   SC200  SC200/200

Reated Capacity: 1000kg/2000kg

Lifting Speed: 36 m/min

Motor Power: 2*11 kw/3*11kw

Inside Cage Size: 3*1.3*2.15m

Standard Section Height: 1.508m


B. Features of construction elevator

1.Reliable quality, long life span, wide application range and convenient maintenance.
2.Key parts of construction elevators driving system are imported and customized with reliable quality.
3.The electrical parts of construction elevators are from world-famous manufactures, such as Schneider, Siemens and Toshiba.
4.The racks and gears adopt special material and heat-treatment technique, prolonging the life span.
5.The steel structure of construction elevator is from famous domestic manufactures with high quality. The surface of the structure can adopt paint-spray or hot galvanized according to your requirements
6.The soft starting and braking makes no impact and the machine can be operated easily and smoothly.
7. The system has over-voltage protection, low-voltage protection, over-current, over-load and over speed protection functions.




1. Minimum Order Quantity? MOQ is One set.
2. What kind of terms of payment? T/T, L/C, Western Union are available.
3. Quotation request:
If you are interested in our products, please provide the following parameters:
1).Lift height(m)

2).Load capacity (kg)
3). Double cage or single cage
4).Local power supply (kV, Hz)
5).Other special equipments
We will provide best price once confirmed the above.


D. Main Performance Parameter

Item Unit SC100 SC100/100 SC200 SC200/200
Rated loading capacity Kg 1000 2×1000 2000 2×2000
Passenger number Person 12 2×12 16 2×16
Rating rising rate M/min 36 36 36 36
Max. lifting height M 200 200 200 200
Motor power KW 2×11 2×2×11 3×11 2×3×11
Cage size M 3*1.3*2.3 3*1.3*2.3 3*1.5*2.3 3*1.5*2.3
Mast section dimension M













Steeve rating rising weight Kg 200 200 200 200
Main material Steel Q345B
Surface treatment Painted or Hot galvanized
Color Red/yellow/blue etc. It can be OEM.

















33m/Min 2 Ton 200m Building Construction Lift 0

33m/Min 2 Ton 200m Building Construction Lift 1

33m/Min 2 Ton 200m Building Construction Lift 2
